Schmidt Digital Tension Meter ETB-100 1unit

Name: Schmidt Digital Tension Meter ETB-100 1unit
Brand: Schmidt
SKU: S040179353
Price: 52999900 IDR
Availability: OutOfStock

#Nomor SKU S040179353

Wishlist

0 Ulasan

Spesifikasi Produk

Model Number	ETB-100
Unit	1unit
Measuring Range (cN)	0.3 – 100.0
Resolution (cN)	0.1
Measuring Head Width (mm)	24
Accuracy	±1 % full scale ±1 digit or better (typical ±0.5 % full scale)
Measuring Units	cN, g, N or lb, switchable
Over Range	Approx. 10 % full scale, without accuracy guarantee
Overload Protection	200 % full scale
Measuring Principle	Strain gauge bridge
Measuring Roller Deflection (mm)	Max. 0.5
Signal Processing	Digital
Sampling Rate Internal (kHz)	approx. 1
Sampling Rate (Hz)	Max. 200 (200 readings/sec)
Display	Colour-TFT 128 x 160
Memory	Last, average, MAX and MIN
Temperature Range (°C)	10 – 45
Air Humidity	85 % RH, max.
Housing Material	Aluminium
Power Supply	LiPo accumulator (approx. 20 h continuous use, charging time approx. 3.5 h), USB AC adapter 100 – 240 V AC with 4 adapters (EU/USA/UK/AUS-NZ)
Berat (Kg)	1.2
Tanggal Produk Terdaftar	25 March 2024
Terakhir Diperbaharui	22 July 2025

Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini

Informasi Produk

Description

Electronic tension meter for hard to reach and limited access space applications.
Available in two models: ETB (Basic unit) and ETX (with memory and outputs)
Hand-held instrument with guide rollers up to max. 2000 m/min
Tension meter with measuring head as small as possible

Peringatan

Exclude sertifikat kalibrasi
