Panasonic Capacitor EEUFR1J221LB Radial Leaded 220µF; 63V 1pc

Name: Panasonic Capacitor EEUFR1J221LB Radial Leaded 220µF; 63V 1pc
Brand: Panasonic
SKU: S037414993
Price: 14000 IDR
Availability: InStock

#Nomor SKU S037414993

Panasonic

Wishlist

0 Ulasan

Spesifikasi Produk

Model Number	EEUFR1J221LB
Unit	1pc
Product Range	FR
Lifetime at Temperature (hour)	10000; at 105°C
Product Diameter (mm)	10
polarity	Polar
Lead Spacing (mm)	5
Minimum Operating Temperature (°C)	-40
Ripple Current (A)	1.5
ESR (ohm)	0.033
Maximum Operating Temperature (°C)	105
Capacitor Case/Package	Radial Leaded
Voltage DC (V)	63
Capacitor Terminals	Radial Leaded
Product Height (mm)	25
Capacitance Tolerance (%)	± 20
Capacitance (µF)	220
Berat (Kg)	0.1
Tanggal Produk Terdaftar	17 July 2023
Terakhir Diperbaharui	27 May 2025

Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini

Informasi Produk

Description

The Panasonic FR series capacitors are type A, radial leaded polarized aluminium electrolytic capacitors. The capacitance value ranges from 4.7µF to 8200µF. These capacitors are perfect solution for applications, which require ultra low ESR, very high ripple current and very long life in small mounting form. In comparison to Panasonic FM series, the FR series capacitors can achieve a endurance upgrade of up to 100% and a capacitance increase of up to 30% by improving material technology.

Feature

Rated voltage range of 6.3VDC to 100VDC

Tolerance of ±20%

Endurance of 5000h to 10000h at 105°C

Operating temperature range -40°C to 105°C

High reliability

Use

Industrial,

Power Management,

Consumer Electronics,

Portable Devices
