Panasonic Capacitor EEEFPE101XAP SMD Aluminium, Radial Can - SMD 100µF; 25V 1pc
Rp5.900
Persediaan
Spesifikasi Produk
| Model Number | EEEFPE101XAP |
|---|---|
| Unit | 1pc |
| Product Range | FP |
| Lifetime at Temperature (hour) | 2000; at 105°C |
| Product Diameter (mm) | 6.3 |
| Qualification | AEC-Q200 |
| polarity | Polar |
| Ripple Current (mA) | 600 |
| Minimum Operating Temperature (°C) | -55 |
| ESR (ohm) | 0.16 |
| Maximum Operating Temperature (°C) | 105 |
| Capacitor Case/Package | Radial Can - SMD |
| Voltage DC (V) | 25 |
| Capacitor Terminals | Solder |
| Product Height (mm) | 7.7 |
| Capacitance Tolerance (%) | ± 20 |
| Capacitance (µF) | 100 |
| Berat (Kg) | 0.1 |
| Tanggal Produk Terdaftar | 17 July 2023 |
| Terakhir Diperbaharui | 08 December 2025 |
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
The EEEFPE101XAP is a FP series type V surface mount polarized Aluminium Electrolytic Capacitor suitable for high temperature lead-free reflow. This capacitor is perfect solution for applications which require ultra low ESR, very high ripple current and very long life.
Feature
3µA (after 2 minutes) DC leakage current600mA RMS at 100kHz/+105°C Rated ripple current
Rated voltage range from 6.3VDC to 50VDC
±20% tolerance
Endurance is 2000h at 105°C
Operating temperature range -55°C to 105°C
Use
Multimedia, Consumer Electronics,
Industrial,
Communications & Networking,
Portable Devices,
Automotive
