Panasonic Capacitor ECA2GHG100 ±20%, Radial Leaded, Polar 10µF; 400V 1pc

Name: Panasonic Capacitor ECA2GHG100 ±20%, Radial Leaded, Polar 10µF; 400V 1pc
Brand: Panasonic
SKU: S037410506
Price: 14000 IDR
Availability: InStock

#Nomor SKU S037410506

Panasonic

Wishlist

0 Ulasan

Spesifikasi Produk

Model Number	ECA2GHG100
Unit	1pc
Product Range	NHG
Lifetime at Temperature (hour)	1000; at 105°C
Product Diameter (mm)	10
Qualification	AEC-Q200
polarity	Polar
Lead Spacing (mm)	5
Ripple Current (mA)	80
Minimum Operating Temperature (°C)	-25
Maximum Operating Temperature (°C)	105
Capacitor Case/Package	Radial Leaded
Voltage DC (V)	400
Capacitor Terminals	Radial Leaded
Product Height (mm)	20
Capacitance Tolerance (%)	± 20
Capacitance (µF)	10
Berat (Kg)	0.1
Tanggal Produk Terdaftar	17 July 2023
Terakhir Diperbaharui	27 May 2025

Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini

Informasi Produk

Description

The Panasonic NHG series is automotive grade Type A, radial leaded polarized aluminium electrolytic capacitor. NHG series parts cover broad range of voltage ratings and capacitance values. Typical applications include audio, video and general purpose electronic circuits.

Feature

Capacitance value ranges 2.2µF to 22000µF for 6.3VDC to 100VDC

Capacitance value ranges 1µF to 330µF for 160VDC to 450VDC

Available in -55°C to 105°C and -25°C to 105°C temperature range based on rated voltage

Capacitance tolerance is ±20%

Endurance at 105°C from 1000h to 2000h

Low ESR and high ripple current

Automotive grade AEC-Q200 compliant

Use

Industrial,

Automotive,

Consumer Electronics,

Portable Devices,

Power Management
