ZOELLER Pompa Celup Elevator
#Grup produk P109585732
Spesifikasi
| UNSPSC | 40151513 |
|---|---|
| Agency Compliance | CSA/UL |
| Alarm Duration | Continuous |
| Alarm Included | Yes |
| Alarm Output | Audible; Dry Contact Remote Terminal; Visual |
| Amps (A) | 8.5 |
| Body Material | Cast Iron |
| Cord Length (ft) | 20 |
| Discharge (inch) | 1-1/2 FNPT |
| Duty cycle | Continuous |
| Flow Rate @ 10ft. of Head (gpm) | 61 |
| Flow Rate @ 20ft. of Head (gpm) | 44 |
| Flow Rate @ 30ft. of Head (gpm) | 23 |
| Frequency (Hz) | 60 |
| Horsepower (HP) | 4/10 |
| Impeller Material | Polypropylene |
| Max. Diameter Solids (inch) | 3/4 |
| Maximum Head (ft) | 38 |
| Maximum Liquid Temperature (°F) | 130 |
| Min. Sump Pit Dia. (inch) | 18 |
| Minimum Water Depth (inch) | 14 |
| Off Point (inch) | 18-1/8 |
| On Point (inch) | 12-1/8 |
| Overall Height (inch) | 12-1/8 |
| Rated Voltage (V) | 115 AC |
| Rotation Speed (rpm) | 3450 |
| Shaft Seal Material - Pumps | Carbon; Ceramic |
| Switch Actuation | Sensor |
| Switch Electrical Connection | Piggyback |
| Width at Widest Point (inch) | 10-3/32 |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
These elevator sump pumps drain water from elevator sump pits and transformer vaults. They have an oil detector that identifies when oil is present. The pump only operates when water is present and stops when oil is sensed. This prevents the pumping of oil into groundwater or sewage systems.
Feature
Elevator Sump Pump with Oil Sensor HP 4/10 Rated Voltage 115V AC Hz 60 Amps 8.5 A Flow Rate @ 10 ft of Head 61 gpm Flow Rate @ 20 ft of Head 44.0 gpm Flow Rate @ 30 ft of Head 23.0 gpm Max Head 38.0 ft Switch Actuation Sensor Switch Electrical Connection Piggyback Off Point 18-1/8 in On Point 12 1/8 in Body Material Cast Iron Impeller Material Polypropylene Shaft Seal Material - Pumps Carbon Ceramic Min Sump Pit Dia 18 in Minimum Water Depth 14 inUlasan Produk
