High accuracy thermocouple temperature calibration the easy way
Fluke 714B is a handheld, battery-operated instrument that measures and sources a variety of thermocouple types and millivolts. It can calibrate a linear thermocouple transmitter with the mV source function and also measure mA while sourcing temperature. It also provides linear ramp and 25% step auto ramp functionality based on 0% and 100% settings for performing quick, linearity checks.
Designed for calibration professionals
With the intelligent shutdown feature the Fluke 714B remembers settings when powered down so you can quickly replicate tests after powering back up. The calibrator also has one-year and two-year specifications, along with a traceable certificate of calibration. Combine that with its rugged construction, a backlit display, and easy to use interface and you have an ideal test tool for temperature calibration professionals who want a highly accurate, single-function thermocouple temperature calibrator.
Related resources
- Process calibration articles and resources
- Simulating thermocouples and RTDs for calibration and testing
- Temperature transmitter calibration
- Process calibration tool selector
Set Content :
714B TC calibrator
Protective Boot (installed)
(4) AA batteries (installed)
Traceable calibration certificate with data
(1 pair) TL75 Test Leads
(1 set) AC175 Alligator clips
Type K beaded TC
TPAK80 magnetic hanger strap
Quick Reference Guide
FLUKE Thermocouple FLK-714B/EN TC 1pc
Rp49.999.900
Persediaan
Spesifikasi Produk
| Model Number | FLK-714B/EN |
|---|---|
| Unit | 1pc |
| Operating Temperature (°C) | -10 to 50 |
| Storage Temperature (°C) | -30 to 60 |
| Temperature Coefficient (°C) | DC mA Measurement : ±(0.002% of reading + 0.002% of range) /°C (< 18 or > 28); Millivolt Measurement and Source : ±(0.002% of reading + 0.002% of range) /°C (< 18 or > 28) |
| Operating Altitude (m) | 2000 |
| IP Rating | IEC 60529: IP52 |
| Safety | IEC 61010-1, Max 30 V to earth, Pollution Degree 2 |
| Storage Altitude (m) | 12000 |
| Relative Humidity (%RH) | Non condensing, 90 (10°C to 30°C), 75 (30°C to 40°C), 45 (40°C to 50°C), (Without condensation) |
| Vibration Requirements | MIL-T-28800E, Class 2 |
| Drop Text Requirements (m) | 1 |
| Electromagnetic Environment | IEC 61326-1, Portable |
| Power Supply | 4 AA NEDA 1.5A IEC LR6 batteries |
| Size (HxWxL) (mm) | 52.5x84x188.5 |
| Resolution (mA) | 0-24 |
| Range (mA) | 0.001 |
| Accuracy (% of reading + counts) (μA) | DC mA Measurement : 0.010% + 2; Millivolt Measurement and Source : 0.015% + 10 |
| Resolution (mV) | -10 to 75 |
| Range (mV) | 0.01 |
| Berat (Kg) | 0.5 |
| Tanggal Produk Terdaftar | 14 November 2023 |
| Terakhir Diperbaharui | 27 May 2025 |
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Feature
Maximum Voltage Applied Between any Terminal and Earth Ground or Between any Two Terminals (V) : 30Ketentuan dan Kondisi Barang
