Panasonic Resistor ERA2AEB103X SMD Chip, 0402 [1005 Metric], Metal Film (Thin Film) 10kohm 1pc

Name: Panasonic Resistor ERA2AEB103X SMD Chip, 0402 [1005 Metric], Metal Film (Thin Film) 10kohm 1pc
Brand: Panasonic
SKU: S037415372
Price: 4000 IDR
Availability: InStock

#Nomor SKU S037415372

Wishlist

0 Ulasan

Spesifikasi Produk

Model Number	ERA2AEB103X
Unit	1pc
Product Range	ERA Series
Qualification	AEC-Q200
Product Length (mm)	1.02
Minimum Operating Temperature (°C)	-55
Product Width (mm)	0.5
Maximum Operating Temperature (°C)	155
Resistor Case/Package	0402 [1005 Metric]
Resistor Technology	Metal Film (Thin Film)
Resistance Tolerance (%)	± 0.1
Temperature Coefficient (ppm/°C)	± 25
Voltage Rating (V)	50
Power rating (mW)	62.5
Resistor Type	High Reliability
Resistance (kΩ)	10
Berat (Kg)	0.1
Tanggal Produk Terdaftar	17 July 2023
Terakhir Diperbaharui	27 May 2025

Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini

Informasi Produk

Description

The Panasonic ERA 2A series resistors are highly reliable, automotive grade metal film chip resistors based on thin film technology. The resistance range includes E24 and E96 decade values from 10 ohm to 1Mohm. ERA series metal thin film chip resistors have small resistance tolerance and temperature coefficient of resistance, low current noise and excellent linearity. These resistors are stable at high temperature and humidity.

Feature

EIA 0201, 0402, 0603, 0805, 1206 case sizes available

Automotive grade AEC-Q200 compliant

Meets IEC 60115-8, JIS C 5201-8, EIAJ RC-2133B standards

85°C 85% RH rated load

Maximum power rating of 250mW

Available in ±0.05%, ±0.1%, ±0.25% and ±0.5% tolerance

±10, ±15, ±25, ±50 and ±100ppm/°C TCR values available

Operating temperature range -55°C to 155°C
