Panasonic Capacitor EEUFR1E221 ±20%, Radial Leaded, Polar 220µF; 25V 1pc

Name: Panasonic Capacitor EEUFR1E221 ±20%, Radial Leaded, Polar 220µF; 25V 1pc
Brand: Panasonic
SKU: S037414788
Price: 4900 IDR
Availability: OutOfStock

#Nomor SKU S037414788

Wishlist

0 Ulasan

Spesifikasi Produk

Model Number	EEUFR1E221
Unit	1pc
Product Range	FR
Lifetime at Temperature (hour)	6000; at 105°C
Product Diameter (mm)	8
polarity	Polar
Lead Spacing (mm)	3.5
Ripple Current (mA)	950
Minimum Operating Temperature (°C)	-40
Maximum Operating Temperature (°C)	105
Capacitor Case/Package	Radial Leaded
Voltage DC (V)	25
Capacitor Terminals	Radial Leaded
Product Height (mm)	11.5
Capacitance Tolerance (%)	± 20
Capacitance (µF)	220
Berat (Kg)	0.1
Tanggal Produk Terdaftar	17 July 2023
Terakhir Diperbaharui	08 December 2025

Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini

Informasi Produk

Description

The Panasonic FR series capacitors are type A, radial leaded polarized aluminium electrolytic capacitors. The capacitance value ranges from 4.7µF to 8200µF. These capacitors are perfect solution for applications, which require ultra low ESR, very high ripple current and very long life in small mounting form. In comparison to Panasonic FM series, the FR series capacitors can achieve a endurance upgrade of up to 100% and a capacitance increase of up to 30% by improving material technology.

Feature

Rated voltage range of 6.3VDC to 100VDC

Tolerance of ±20%

Endurance of 5000h to 10000h at 105°C

Operating temperature range -40°C to 105°C

High reliability

Use

Industrial,

Power Management,

Consumer Electronics,

Portable Devices
