Panasonic Capacitor ECA0JM102 ±20%, Radial Leaded, Polar 1000µF; 6.3V 1pc

Name: Panasonic Capacitor ECA0JM102 ±20%, Radial Leaded, Polar 1000µF; 6.3V 1pc
Brand: Panasonic
SKU: S037409722
Price: 3900 IDR
Availability: OutOfStock

#Nomor SKU S037409722

Wishlist

0 Ulasan

Spesifikasi Produk

Model Number	ECA0JM102
Unit	1pc
Product Range	M
Lifetime at Temperature (hour)	2000; at 85°C
Product Diameter (mm)	8
polarity	Polar
Lead Spacing (mm)	3.5
Ripple Current (mA)	580
Minimum Operating Temperature (°C)	-40
Maximum Operating Temperature (°C)	85
Capacitor Case/Package	Radial Leaded
Voltage DC (V)	6.3
Capacitor Terminals	Radial Leaded
Product Height (mm)	11.5
Capacitance Tolerance (%)	± 20
Capacitance (µF)	1000
Berat (Kg)	0.1
Tanggal Produk Terdaftar	17 July 2023
Terakhir Diperbaharui	08 December 2025

Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini

Informasi Produk

Description

The Panasonic M series capacitors are automotive grade type A, radial leaded polarized aluminium electrolytic capacitors. The M series parts cover broad range of voltage ratings and capacitance values. These capacitors are perfect solution for applications, which require ultra low ESR, very high ripple current and very long life in small mounting form.

Feature

Capacitance value ranges from 2.2µF to 22000µF for 6.3VDC to 100VDC

Capacitance value ranges from 1µF to 470µF for 160VDC to 450VDC

Automotive grade AEC-Q200 compliant

Tolerance of ±20%

Endurance of 2000h at 85°C

Available in -40°C to 85°C and -25°C to 85°C temperature ranges based on rated voltage

High reliability
