AS ONE Thermax Oil Bath TM-4A With Inspection Certificate 1pc

Name: AS ONE Thermax Oil Bath TM-4A With Inspection Certificate 1pc
Brand: AS ONE
SKU: S036485215
Price: 29999900 IDR
Availability: InStock

#Nomor SKU S036485215

AS ONE

Wishlist

0 Ulasan

Spesifikasi Produk

Model Number	TM-4A
Unit	1pc
Temperature Control Accuracy (°C)	±2.0 (Our Company test value)
Body Dimensions (mm)	147x150x295
Clamp Attachable Width (mm)	40
Heater Capacity (kW)	1.2
Sensor Resistance (ohm)	Pt100
Stirring Mechanism	propeller stirring type
Power Supply (50/60Hz) (VAC)	100
Temperature Adjustment Range (°C)	R.T. + 5 to 180
Temperature Settings Range (°C)	20.0 to + 180 (There is no cooling function on the main unit. Use an external cooling device (Options). )
Function	Program (Up to 8 steps), Float type anti-blank firing, buzzer alarm, variable type over-temperature prevention device
Timer Setting Range	1 minute to 99 hours 59 minutes (Per minute)
Package Size (mm)	410x250x190
M Code	41709798
Berat (Kg)	8.0
Tanggal Produk Terdaftar	31 May 2023
Terakhir Diperbaharui	15 August 2025

Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini

Informasi Produk

Peringatan

Standar JEPANG.. Produk Elektronik menggunakan POWER SUPPLY standar JEPANG (110V). Mohon tanyakan terlebih dahulu. REKOMENDASI TRAFO : S041707319 (USA), S010836781 (JPN), atau S037607586 (Lokal)
Untuk lebih detail terkait kepastian ketersediaan stok harap menghubungi kami terlebih dahulu.

Warning

Image on this page only as Representative Image, Please check the specifications of each model number for details.
