Mitutoyo Dial Bore Gauges Inch 511-752 1.4-2.5/0.0001IN 1pc

Name: Mitutoyo Dial Bore Gauges Inch 511-752 1.4-2.5/0.0001IN 1pc
Brand: Mitutoyo
SKU: S030178403
Price: 5699900 IDR
Availability: InStock

#Nomor SKU S030178403

Mitutoyo

Wishlist

0 Ulasan

Spesifikasi Produk

Model Number	511-752
Unit	1pc
Range (inch)	1.4-2.5
Graduation (inch)	0.0001
Dial Gage	2923S-10
Number of Anvils	6
Number of Spacers	4
Technology	Mechanical
Units	Inch
Stem Diameter (inch)	3/8
Contact point	Carbide Tipped
Accuracy (inch)	8e-05
Adjacent Error (inch)	4e-05
With Dial Gage Protective Cover (21DZA000)	Yes
Repeatability (inch)	2e-05
Berat (Kg)	1.0
Tanggal Produk Terdaftar	13 December 2021
Terakhir Diperbaharui	31 July 2025

Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini

Informasi Produk

Description

The Mitutoyo standard type bore gage is available in several different inch ranges to measure inside bore diameters with accuracy to .00008”. The bore gage comes with interchangeable anvils to measure different bore diameters with the same gage. A pendulum guide structure permits the slide of the gage for measurements while a two-point contact system detects geometry anomalies such as ovalness and taper.

Feature

Available with a Mitutoyo Dial Indicator
Available in Inch models
Optional extension rods are available to measuring deep hole with accuracy
Large, newly designed grips are easier to hold and reduce heat transfer from the operator for better accuracy
Fully protected by a rugged cover
Gage stem diameter is .375”
Interchangeable anvils are constructed of alloy steel with carbide-tipped measuring faces for added accuracy and durability
Supplied in a fitted plastic case
