Small double-equipped limit switch with improved sealability, impact resistance and strength The double-seal structure of the rotary shaft of the limit switch is further strengthened, and sealability is secured by a gasket full cover system.
Wide temperature specifications (-40 to 100°C: standard type)
Adopts a block mount method that minimizes time loss during maintenance.
Acquired UL, CSA and CCC standards.
OMRON Compact Heavy Equipment Limit Switch D4a-N D4A-1101N-F 1pc
Rp1.499.900
Persediaan
Spesifikasi Produk
| Model Number | D4A-1101N-F |
|---|---|
| Unit | 1pc |
| Internal capacity | 1 piece |
| Product Number | D4A-1101N-F |
| format | Shape D4A-1101N-F |
| Kinds | Set Type (2-Circuit double-cut Type) |
| Type | Rotating Lever Type, Standard Type |
| Actuator Type | Rotating lever type, standard type |
| Head Shape | Rotating Lever Type, Standard Type |
| Operation Indicator Lamp | None |
| Protection Class | (Compliant) IP67, NEMA standards 1, 2, 3, 4, 4X, 5, 6P, 12, 13 |
| Rated Frequency (Hz) | 50/60 |
| Temperature Rise (°) | 50 or less |
| Contact Resistance (miliΩ) | 25 or less (initial value) |
| Impact Resistance Durability (m/s²) | 1000 or m ore |
| Ambient Relative Humidity (RH) | 35 to 95 (with no icing) |
| Allowable Operating Speed (mm-m/s) | 1 to 2 (D4A-3101N, rotating lever type) |
| Pollution Degree (Environment to Use) | 3 |
| Inrush Current (A) | (Normally closed circuit) up to 30A, (normally open circuit) up to 20A |
| Withstand Voltage | (Between terminals of the same polarity) 1000V AC 50/60Hz 1min (Between live metal parts and earth) 2200V AC 50/60Hz 1min (Between each terminal and non-current metal parts) 2200V AC 50/60Hz 1min |
| Electrical Durability | 1 million times or more (2 circuit double cut type: AC125V 10A resistance load) |
| Operation | 2-circuit double break type |
| Mechanical Durability (times) | 50 million or more (for 2-circuit double-break rotary lever type) *Excluding holding type. |
| Electric Shock Protection Class | Class I (with ground terminal) |
| M Code | 66458297 |
| Berat (Kg) | 0.5 |
| Tanggal Produk Terdaftar | 23 November 2021 |
| Terakhir Diperbaharui | 02 October 2026 |
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Feature
Small heavy equipment limit switch with improved sealability, impact resistance, strength resistanceFurther strengthening the double seal structure of the rotating shaft portion and secures sealing performance by a gasket full cover method.
Wide temperature specification (-40 to 100°C: standard type)
A block mounting method is used to minimize time loss during maintenance.
UL, CSA, CCC Standard Acquisition.
