Small general-purpose horizontal type.
Micro load type is also available in series
EN, UL, CSA, and CCC standards. Built into a robust and precise die-cast case with a highly durable coil spring switch.
It is small and can be used for applications where strength is uneasy when the micro switch is used alone.
The cord can be pulled out from either the left or right side by replacing the terminal protection cover.
Sealing performance conforming to IEC IP67.
OMRON Compact Enclosed Switch SHL Hinge/Roller/Lever Type SHL-W2155-MLVCTF1M 1pc
Rp829.900
Persediaan
Spesifikasi Produk
| Model Number | SHL-W2155-MLVCTF1M |
|---|---|
| Unit | 1pc |
| Internal capacity | 1 piece |
| Withstand Voltage | (Between same pole Terminals) AC1000V 50/60Hz 1min (between each Terminal and non-charged Metal Part) AC2000V 50/60Hz 1min/Uimp 2.5kV (EN60947-5-1) |
| Product Number | SHL-W2155-MLVCTF1M |
| format | Shape SHL-W2155-MLVCTF1M |
| Type | General form |
| Type Of Actuator | Hinge / roller / lever type |
| Rated Voltage (V) | AC125, 250, 500, DC8, 14, 30, 125, 250 |
| Operation Indicator | No Operation Indicator |
| Protective Structure | IP67 (EN60947-5-1) |
| Rated Insulation Voltage (V) | (Ui) 150 (EN60947-5-1) |
| Rated Frequency (Hz) | 50/60 |
| Wire Length (m) | 1 (VCTF 0.75x3 cores) |
| Operating Ambient Temperature (°C) | -10 to 80 (however, do not freeze) |
| Contact Resistance (miliΩ) | 15 or less (initial value, built-in Switch alone) |
| Wire Diameter (mm) | (Lead Wire) 0.18 |
| Impact Resistance (Durability) | 1000m/s |
| Operating Ambient Humidity | 35-95% RH (however, do not freeze) |
| Vibration Resistance (Malfunction) | 10-55Hz Double amplitude 1.5mm |
| M Code | 66519906 |
| Berat (Kg) | 0.5 |
| Tanggal Produk Terdaftar | 23 November 2021 |
| Terakhir Diperbaharui | 02 October 2026 |
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Peringatan
PERHATIAN: Produk ini dirancang untuk tegangan 100/110/120V (Produk Impor). Penggunaan dengan tegangan yang berbeda dapat mengakibatkan kerusakan atau bahaya, karena tegangan listrik yang umum dipakai di Indonesia adalah 220V.Feature
Small general purpose horizontal type.Microbaring type is also serialized
EN, UL, CSA, CCC Standard Get
Built-in high-durable and high-durable coil spring switch to a robust and precise die casting case.
Small and micro switch alone can be used for intense uneasy applications.
The drawing direction of the code can be drawn from either side left or right by replacing the terminal protective cover.
Sealing that matches IEC IP67.
