Small general-purpose horizontal type.
Micro load type is also available in series
EN, UL, CSA, and CCC standards. Built into a robust and precise die-cast case with a highly durable coil spring switch.
It is small and can be used for applications where strength is uneasy when the micro switch is used alone.
The cord can be pulled out from either the left or right side by replacing the terminal protection cover.
Sealing performance conforming to IEC IP67.
OMRON Compact Enclosed Switch SHL Hinge/Roller/Lever Type
#Grup produk P105934116
Spesifikasi
| Internal capacity | 1 piece |
|---|---|
| Withstand Voltage | (Between same pole Terminals) AC1000V 50/60Hz 1min (between each Terminal and non-charged Metal Part) AC2000V 50/60Hz 1min/Uimp 2.5kV (EN60947-5-1) |
| Type | General form |
| Type Of Actuator | Hinge / roller / lever type |
| Contact Resistance (miliΩ) | 15 or less (initial value, built-in Switch alone) |
| Impact Resistance (Durability) | 1000m/s |
| Operating Ambient Humidity | 35-95% RH (however, do not freeze) |
| Operating Ambient Temperature (°C) | -10 to 80 (however, do not freeze) |
| Operation Indicator | No Operation Indicator |
| Protective Structure | IP67 (EN60947-5-1) |
| Rated Frequency (Hz) | 50/60 |
| Rated Insulation Voltage (V) | (Ui) 150 (EN60947-5-1) |
| Rated Voltage (V) | AC125, 250, 500, DC8, 14, 30, 125, 250 |
| Vibration Resistance (Malfunction) | 10-55Hz Double amplitude 1.5mm |
| Wire Diameter (mm) | (Lead Wire) 0.18 |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Feature
Small general purpose horizontal type.Microbaring type is also serialized
EN, UL, CSA, CCC Standard Get
Built-in high-durable and high-durable coil spring switch to a robust and precise die casting case.
Small and micro switch alone can be used for intense uneasy applications.
The drawing direction of the code can be drawn from either side left or right by replacing the terminal protective cover.
Sealing that matches IEC IP67.
