OMRON Counter H7CX Series (Penghitung Digital) H7CX-R11-N OMI 1pc

Standard
(UL): Standard number: UL508
File No.: E41515
(CSA): Standard number: CSA C22.2 No.14
File No.: LR22310
(EC Directive (Machine Directive)): EN61010-1
(EC Directive (Low Voltage Directive)): EN61010-1
(EC Directive (EMC Directive)): EMI: EN61326
Radiated disturbance electric field strength: EN55011 Group 1 Class A
Noise terminal voltage: EN55011 Group 1 Class A
EMS: EN61326
Electrostatic discharge immunity: EN61000-4-2 (4kV contact; 8kV air)
Field strength immunity: EN61000-4-3 (10V/m AM modulation (80MHz to 1GHz); 10V/m pulse modulation (900MHz±5MHz))
Conducted noise immunity: EN61000-4-6 (10V(0.15~80MHz))
Burst noise immunity: EN61000-4-4 (2kV power line; 1kV I/O signal line)
Surge immunity: EN61000-4-5 (1kV between lines (power line, output line); 2kV between earth (power line, output line))
Voltage dip/disconnection immunity: EN61000-4-11 (0.5 cycle, 100% (rated voltage))

Withstand voltage
Between live metal parts and non-live metal parts: AC2000V 50/60Hz 1min
Between power supply and input circuit: AC2000V 50/60Hz 1min
Between control output and power supply, input circuit: AC2000V 50/60Hz 1min
Between discontinuous contacts: AC1000V 50/60Hz 1min

Input method
No-voltage input/voltage input (switching)
(Non-contact input): Impedance at short circuit: 1kΩ or less
Outflow current at 0Ω: Approx. 12mA
Residual voltage during short circuit: 3V or less
Impedance when open: 100kΩ or more
Maximum applied voltage: DC30V or less
(Contact input): Use a contact that can sufficiently open and close 10V 5mA.
Voltage input: H level: DC4.5~30V
L level: DC0~2V
Input resistance: Approximately 4.7kΩ
Applicable 2-wire sensor: Leakage current: 1.5mA or less
Switching capacity: 5mA or more
Residual voltage: DC3.0V or less
Power supply used: Must operate with DC10V
