Mitsubishi Electric Three-phase automatic power factor controller VAR series
#Grup produk P112485751
Spesifikasi
| Adjustment Method | (Automatic power factor) reactive power detection method |
|---|---|
| Control Output | Number of capacitor circuits → 12 circuits Output contact → Constantly energized output a contact Contact capacity → AC250V 1A, DC110V 0.1A |
| Insulation Resistance (MΩ) | 10 or more (DC500V) at the same location as \"Power frequency withstand voltage\" |
| Mass (kg) | 0.9 |
| Maximum Input Rating | Voltage → Three-phase three-wire: AC110/220V, Three-phase four-wire: Maximum AC254V (phase voltage) Current → AC5A Frequency: 50/60Hz |
| Operating Humidity Range (%RH) | 30 to 85°C (no condensation) |
| Operating Temperature Range (°C) | -5 to 50 (average daily operating temperature 35°C or less) |
| Outer Dimensions (mm) | 144(H)x144(W)x98(D) |
| Output | Operation complete. Output ON complete → Terminals CE+ and E- open. Cut-off complete → Terminals TE+ and E- open. Output contact → No-voltage a contact, one side common, contact capacity 24V DC 0.1A. |
| Power Consumption (VA) | Voltage circuit → each phase 0.1 (110V), 0.2 (220V) Current circuit → each phase 0.1 Auxiliary power circuit → 15 (AC110V) 19 (AC220V) 9W (DC110V) |
| ROHS Directive (Corresponding to 10 Substances) | Correspondence |
| Response Time (s) | 2(Supplement 1) |
| Suitable Circuit | Three-phase 3-wire, three-phase 4-wire common |
| Type of Sign | Embedded mounting |
| Type of control | Automatic → Cyclic/Priority/Optimal Control Method Manual → Manual ON/Manual OFF |
