Mitsubishi Electric Power management instrument M8HM series
#Grup produk P112483434
Spesifikasi
| Apparent power (VA) | Burden (average) Voltage circuit → P1-P2: 0.24/P3-P2: 0.01, Current circuit → 1S-1L: 0.04/3S-3L: 0.04 |
|---|---|
| Conformed Standard | IS C 1216-1/2 Watt-hour meter (transformer combination meter), JIS C 1271-1 AC electronic watt-hour meter, JIS C 1102-2/3/5 Voltmeter, ammeter, wattmeter, power factor meter (measurement accuracy only) |
| Mass (kg) | 0.7 |
| Measurement content | Electric energy (measured value): Standard class |
| Outer Dimensions (mm) | W72 x H144 x D106.5 (inside panel depth 94.5) |
| Power Loss (W) | Burden (average) Voltage circuit → P1-P2: 0.24/P3-P2: 0.01, Current circuit → 1S-1L: 0.04/3S-3L: 0.04 |
| Pulse Output | ○ (non-voltage contact, 2 points) |
| ROHS Directive (Corresponding to 10 Substances) | Correspondence |
| Rated Current (A) | 5 |
| Setting Range | VT primary voltage/CT primary current: Yes Pulse unit/pulse width: Yes |
| Specification | ●Multiplying factor (power): Integer powers of 10 ●Supports incorrect connection detection: Neutral line → -, incorrectly connected phase → 1/3 (incorrectly connected phase is displayed) |
| Status Display | Operation/No load/Reverse current |
| Type | Ordinary watt-hour meter/unidirectional meter |
| Type Approval No. | 4776 |
| Type of Sign | Embedded type |
| Weatherability | Indoor weather |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Warning
If the delivery destination is a private residence (detached house/complex housing), the store name is required. Please note that delivery may not be possible if there is no store name.Ulasan Produk
