Mitsubishi Electric GOT2000 series wide model
#Grup produk P112477992
Spesifikasi
| Accuracy | Internal clock: ±90 seconds/month (ambient temperature 25°C) |
|---|---|
| Atmosphere | During use: No soot, corrosive gas, combustible gas, conductive dust, direct sunlight (same for storage) |
| Battery | GT11-50BAT type lithium battery (lifetime approx. 5 years/ambient temperature 25°C) |
| Conform to | [Software] GT Works3 Version 1.250L or later |
| Cooling Method | Self-cooling |
| Dimensions (Width W x Height H) (mm) | 261 x 12 x 163.2 (display), 290.5 x 210.5 (panel cut) |
| Display | TFT color LCD |
| Display Color | 65536 colors |
| Inrush Current (A) | 59 or less (2 ms, ambient temperature 25°C, maximum load) |
| Installation Altitude (m) | 2000 or less |
| Installation Location | Inside the control panel |
| Insulation Resistance (MΩ) | 10 or more (Between power supply terminals ⇔ ground/by DC500V insulation resistance tester) |
| LED Life (hour) | Approx. 50000 (time when the display brightness reaches 50% at an ambient temperature of 25°C) |
| Light Color | 2 colors (blue, orange) |
| Mass (kg) | 1.7 (excluding mounting bracket) |
| Operating Temperature/Humidity Range | 0 to 55°C/10 to 90% RH (non-condensing) |
| Outer Dimensions, Width W x Depth D x Height H (mm) | 299x48x219 |
| Pollution Degree (Environment to Use) | 2 or less |
| Power Consumption (W) | At maximum load: 20 or less, main unit alone: 14, main unit backlight off: 8 |
| Power Supply Voltage (V) | DC24(+25%/-20%) |
| Protection Class | Front: IP67F, Inside panel: IP2X |
| Resolution | 1280 x 800°C |
| Safety Standard | CE, UL, cUL, EAC, KC |
| Screen Size | 12.1-inch WXGA |
| Service Life | 1 million times or more (operating force 0.98 N or less) |
| Specification | [Overvoltage category] II or lower |
| Temperature / Humidity Range for Storage | -20 to 60°C/10 to 90% RH (no condensation) |
| Vibration Resistance | Conforms to JIS B 3502 and IEC 61131-2 |
