Mitsubishi Electric Collective earth leakage monitoring device
#Grup produk P112475435
Sebelum PPN:
Rp27.999.900 - Rp60.999.900
Ketersediaan:
Periksa Metode Pembayaran dan Estimasi pengiriman
Spesifikasi
| Alarm Output | .Individual output for each circuit/All circuits output together: When an alarm is output for one or more individual outputs, it will be output simultaneously. .System output: It will be output when this instrument is not operating normally. |
|---|---|
| Color | Black (N2.0) |
| Conformed Standard | JIS C 8374 \"Earth leakage relay\" |
| Insulation Resistance (MΩ) | 10 or more (DC500V) at the same location as \"withstand voltage\" |
| Mass (kg) | 0.9 |
| Maximum Operating Voltage (V) | AC600 (for low voltage circuits) |
| Measurement Range | Leakage current Io |
| Operating Temperature Range (°C) | -5 to 50 (average daily operating temperature 35°C or less) |
| Outer Dimensions (mm) | 144(H)x144(W)x98(D) |
| Output | Alarm contact output_Output element → Sensitivity current/EPAL (setting) |
| Power Supply Voltage (V) | Auxiliary power supply → AC100-240 (-20%, +10%) 50/60Hz DC100 (-25%, +40%) External switch SA power supply → AC100-240 (-20%, +10%) 50/60Hz DC100 (-25%, +40%) |
| ROHS Directive (Corresponding to 10 Substances) | Correspondence |
| Rated Sensitivity Current (mA) | 30-50-100-200-400-500-800-1000-1500-2000-3000-4000 (setting) |
| Return Function | Alarm output → Automatic recovery/Manual recovery (setting) |
| Storage Temperature Range (°C) | -20 to 60 |
| Type of Sign | Embedded mounting |
