OMRON Solid State Relay AC Input Unit G32A-B
#Grup produk P112446576
Spesifikasi
| Ambient Humidity to Use (%RH) | 45~85 |
|---|---|
| Input Voltage (V) | AC75~132 |
| Operating Ambient Humidity (%RH) | 45~85 |
| Operating Temperature Range (°C) | -30 to 80 (no condensation or freezing) |
| Operating Voltage | 75% or less of rated voltage |
| Output Current (mA) | 15 |
| Output Voltage | DC12V±15% |
| Rated Input Current (mA) | AC100V(200V) : 21.4 TYP.(50Hz)/AC120V(240V) : 26.5TYP.(50Hz), AC100V(200V) : 25.4 TYP.(60Hz)/AC120V(240V) : 31.6 TYP.(60Hz) |
| Rated Input Voltage (V) | AC100/AC120 |
| Rated Voltage (V) | AC100/120 |
| Return Time (ms) | Less than 1.5 cycles of load power supply |
| Return Voltage | 10% or less of rated voltage |
| Shock (m/s²) | 300 |
| Storage Temperature (°C) | -30 to 100 (no condensation or freezing) |
| Storage Temperature Range (°C) | -30 to +100 (with no icing or condensation) |
| Type | Solid state/relay |
| Vibration | 10 to 55 to 10 Hz, single amplitude 0.375 mm (double amplitude 0.75 mm) (when mounted on DIN rail) |
| Vibration Resistance (Hz) | 10 to 55 to 10, single amplitude 0.375 mm (double amplitude 0.75 mm) (when DIN rail is mounted) |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Warning
For products whose delivery date is confirmed each time, we display a [tentative delivery date] because we need to confirm the delivery date with the supplier each time you place an order, including the production status.After placing your order, we will confirm the delivery date with the supplier, and depending on the number of delivery days, we may ask you if you would like to continue making arrangements.
Please check the details in the information you will receive from the manufacturer at a later date.
Feature
AC input unit that enables AC operation.Ulasan Produk
