Spesifikasi
| Air Flow Volume (m³/hour) | Inflow : 173/ Downflow : 369/ Exhaust : 173/ Required Exhaust with Optional Thimble Exhaust Collar : 260 |
|---|---|
| Average Air Velocity (m/s) | Inflow : 0.45/ Downflow : 0.30 |
| Cabinet Construction | Main body : 1.2mm 18ga electro-galvanized steel with white oven-baked epoxy-polyester Isocide antimicrobial powder-coated; Work Zone : 1.5mm 16ga stainless steel 304, with 4B finish; Side Walls : UV-absorbing tempered glass, 5mm, colorless and transparent |
| Cabinet Full Load Amps (FLA) | 1.8 |
| External Dimension (WxDxH) (mm) | 730x810x1400 |
| Fluorescent Lamp Intensity (Lux) | 859 |
| Fluorescent Lamp Intensity (foot-candles) | 80 |
| Heat (BTU/hour) | 324 |
| Internal Dimension (WxDxH) (mm) | 610x580x660 |
| Power Consumption (W) | 95 |
| Size (m) | 0.6 |
| Static Pressure for Optional Thimble Exhaust Collar (Pa) | 28 |
| Tested Opening (mm) | 175 |
| ULPA Filter Typical Efficiency (%) | >99.999 at 0.1 to 0.3 micron, ULPA as per IEST-RP-CC001.3 USA; >99.999 at MPPS, H14 as per EN 1822 EU |
| Usable Work Area (m²) | 0.27 |
| Working Opening (mm) | 190 |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Informasi Produk
Description
- Class II according to DIN 12469
- Ergonomically angled and frameless front sash
- A large easy-to-read digital display and ergonomically sized touchpad
- Tempered glass side walls (S-Series with stainless steel side walls)
- Esco triple-wall design with negative pressure prevents the possibility of contamination from leaks
- ISOCIDE antimicrobial coating on all painted surfaces minimises contamination
- Quickstart Mode
- Sentinel-Microprocessor maintains steady blower speed
- RS232 serial interface port
- More options on request, e.g. prefilter at intake socket
Model variations:
Model type E and S: Single ULPA-Filter/H14
Model type G: Dual ULPA-Filter/H14
Options on request:
Electrical outlet, support stand, prefilter, service fixture, UV lamp, IV bar, single piece work surface for E-Series, IQ/OQ or KI DISCUS test.
- Ergonomically angled and frameless front sash
- A large easy-to-read digital display and ergonomically sized touchpad
- Tempered glass side walls (S-Series with stainless steel side walls)
- Esco triple-wall design with negative pressure prevents the possibility of contamination from leaks
- ISOCIDE antimicrobial coating on all painted surfaces minimises contamination
- Quickstart Mode
- Sentinel-Microprocessor maintains steady blower speed
- RS232 serial interface port
- More options on request, e.g. prefilter at intake socket
Model variations:
Model type E and S: Single ULPA-Filter/H14
Model type G: Dual ULPA-Filter/H14
Options on request:
Electrical outlet, support stand, prefilter, service fixture, UV lamp, IV bar, single piece work surface for E-Series, IQ/OQ or KI DISCUS test.
