Mitutoyo Surface Roughness
#Grup produk P111294028
Spesifikasi
| Accuracy (µm) | X = (0,8+0,015L) [L : Drive length (mm)] Z1 = (1,2+I2HI/100) [H : Measurement height from the horizontal position (mm)] |
|---|---|
| Axis Range (mm) | 60 (Z1); 200 (X); 500 (Z2) |
| Detector 0.75 mN | Yes |
| Detector Measuring Force (mN) | 0.75 |
| Drive Speed (mm/s) | X: 0 - 80; Z2: 0 - 40 |
| Granite Base Size (WxD) (mm) | 600 x 450 |
| Granite Size (WxD) (mm) | 600 x 450 |
| Inclining Range (°) | ±45 |
| Measuring Speed (mm/s) | 0.02 - 30 |
| Profiles | Primary Profile (P), Roughness Profile (R), Waviness (W), MOTIF (P, R, W) and more |
| Range (µm) | 800; 80; 8(up to 2.4mm with an optional stylus) |
| Traverse (mm) | 200 |
| Traverse Straightness (µm) | (0,1+0,002L) |
| Type | Metric |
| Vertical Travel (mm) | 500 |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
A high-accuracy 2D surface roughness and contour measuring instrument; the Avant D3000 is a benchtop machine and comes with a motorised granite column and stand.Main benefits:"Hot plug" exchange of drive unitsEasy to operateHigh accurate surface roughness and contour measurementsLarge vertical range and very high resolutionA large range of optional arms and styli ensures access to restricted featuresRemote control box for quick and accurate machine positioningSimplified CNC operationOptional motorised accessories
