Protection Functions:
Motor overload protection
Phase failure detection
Phase sequence monitoring
Adjustable current limiting
Interface: Screw-type or spring terminals for power and control wiring
ABB Power Contactor
#Grup produk P111156737
Spesifikasi
| Approvals | CE, cULus, CCC, EAC |
|---|---|
| Depth (mm) | 120 to 200 |
| Height (mm) | 150 to 300 |
| Operating Temperature (°C) | -25 to +60 |
| Product Name | ABB PSR Softstarter |
| Rated Control Supply Voltage (US) (VAC/DC) | 24 or 100-240 |
| Rated Operational Current (A) | 3 to 105 at 40°C |
| Rated Operational Voltage (UE) (VAC) | 208 to 600 |
| Rated Power at 400V (kW) | 1.5 to 55 |
| Rated Power at 460 V (HP) | 2 to 75 |
| Relative Humidity (%) | 5 to 95, non-condensing |
| Standard Compliance | IEC 60947-4-1 |
| Standards | IEC/EN 60947-4-1, UL 508, CSA C22.2 No. 14 |
| Storage Temperature (°C) | -40 to +70 |
| Width (mm) | 45 to 105 |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Feature
Start-up Mode: Voltage ramp, current limitingBuilt-in Bypass: Yes, integrated bypass contactor for energy efficiency
Motor Protection: Overload protection, adjustable current limiting
Adjustable Parameters: Start/stop ramp time, starting voltage, current limit
Communication Capabilities: Optional communication modules available for Modbus, PROFIBUS, DeviceNet, etc.
Diagnostics: LED status indicators for operational and fault states
