DS-ARC1 C6 A30 Arc fault detection device integrated with RCBO
DS-ARC1 is a 1P+N arc fault detection device (AFDD) with an integrated RCBO in three modules, for the protection against earth arc faults, parallel arc faults, series arc faults, overvolatge, short-circuit currents, overload, earth fault currents
ABB Arc Fault Detection Device Integrated with RCBO
#Grup produk P106985108
Sebelum PPN:
Rp4.099.900 - Rp5.399.900
Ketersediaan:
Periksa Metode Pembayaran dan Estimasi pengiriman
Spesifikasi
| Connecting Capacity (mm²) | Busbar 10, Rigid 1-25, Flexible 1-25 |
|---|---|
| Built-in Depth (mm) | 69 |
| Auxiliary Voltage AC/DC (V) | 230 |
| Accessory Type | Auxiliary contact, Signal contact / auxiliary contact, Shunt trip, Undervoltage release, Overvoltage release, Auxiliary contact for bottom fitting |
| Actuator Type | Toggle - Insulation group II, Orange RAL 2004, sealable in ON-OFF-positions |
| Cable Size (mm²) | 25 |
| Contact Position Indication | Red ON / Green OFF |
| Dielectric Test Voltage (kV) | 2.5 |
| Electrical Endurance (cycle) | 10000 |
| Energy Limiting Class | 3 |
| Fault Indication | Blue flag on toggle |
| Frequency (Hz) | 50 |
| Housing Type | Insulation group I, RAL 7035 |
| Leakage Current Type | A |
| Mechanical Endurance (cycle) | 20000 |
| Mounting Position | Any |
| Mounting Position of Accessories | Right |
| Number of Poles | 2 |
| Number of Protected Poles | 1 |
