OMRON Solid State Relay AC Input Unit G32A-B
#Grup produk P106930393
Spesifikasi
| Vibration Resistance | 10 to 55 to 10 Hz, single amplitude 0.375 mm (double amplitude 0.75 mm) (when DIN rail is mounted) |
|---|---|
| Return Voltage | 10% or less of rated voltage |
| Operating Voltage | 75% or less of rated voltage |
| Return Time (ms) | Less than 1.5 cycles of load power supply |
| Ambient Relative Humidity (RH) | 45 to 85 |
| Operating Ambient Temperature (°C) | -30 to +80 (with no icing or condensation) |
| Operating Time (ms) | Less than 1.5 cycles of load power supply |
| Output Current (mA) | 15 |
| Output Voltage | DC12V±15% |
| Rated Current (mA) | (Input) (50Hz) 21.4TYP./20.9TYP., (60Hz) 25.4TYP./31.6TYP. |
| Shock Resistance (m/s2) | 300 |
| Storage Temperature Range (°C) | -30 to +100 (with no icing or condensation) |
| Type | Solid state/relay |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
AC input unit that enables AC operation.
