NSK Deep Groove Ball Bearings 6800 Series ZZ with Retaining Ring
#Grup produk P106590469
Spesifikasi
| Dimensions r0 (mm) | (Maximum) 0.25 |
|---|---|
| Basic load rating Cor (N) | 2470 |
| Basic Load Rating Cr (N) | 4000 |
| Mounting dimensions (minimum Dx) (Φmm) | 35.5 |
| Mounting dimensions (maximum Cx) (mm) | 1.8 |
| Outer Ring Type | With retaining ring |
| Allowable Grease Lubrication Rotation Speed (rpm) | 22000 |
| Dimensions rN (mm) | (Minimum) 0.3 |
| Identification Number | 6804 |
| Inner Diameter d (Φmm) | 20 |
| Load Direction | Radial |
| Mass (g) | 17 |
| Mounting dimension, maximum Da (Φmm) | 30 |
| Mounting dimension, maximum ra (mm) | 0.3 |
| Number of track trains | Single row |
| Outer Diameter d (mm) | 32 |
| Race ring Shape | Deep groove ball bearings |
| Rolling Element Material | High carbon chromium bearing steel |
| Shield Shape | Shielded On Both Sides |
| Width B (mm) | 7 |
