STS Digital Inclinometer
#Grup produk P103664499
Spesifikasi
| Bubble tube sensitivity | 0.50mm / m = 0.0286 degrees |
|---|---|
| Minimum Display | Minimum display: 0.05 degrees (% display is converted in 0.05 degrees units and displayed to the second decimal place) (mm / m display is converted in 0.05 degrees units and displayed as an integer) |
| Continuous Use Time | Approx. 50 hours (when using alkaline batteries) (depends on the usage environment) |
| Power Supply | 2 x AAA batteries |
| Angle (degrees) | Detection range: 360 (90 in 4 directions and 100% in 8 directions) |
| Bubble tube accuracy | +/- 1.5mm / m = +/- 0.0859 degrees |
| Detection Accuracy | 0 degrees, 90 degrees, 180 degrees, 270 degrees position +/- 0.1 degrees, other = +/- 0.2 degrees |
| Display | LCD display (degrees,%, mm / m selectable), 0 degrees, 90 degrees, 180 degrees, 270 degrees (0% display) position, buzzer sound (OFF possible) |
| Display Mode | Normal mode, comparison mode switchable |
| Dust And Waterproof Performance | IP54 equivalent |
| Operating Humidity Range | Less than 70% non-condensing |
| Operating Temperature Limit | 0 degrees Celsius to + 40 degrees Celsius No condensation |
| Size (mm) | 254 x 59 x 28 |
| TRUSCO Number | 148-7083 |
| Weight (g) | 390 (including battery) |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Feature
The liquid crystal display becomes an LED display, making it easy to read the values even in the dark. Any angle can be set as the reference 0 degrees, and comparison display with other angles is possible. When the main unit is turned upside down, the numerical value on the digital display is also inverted. Equivalent to dustproof and waterproof IP54 and can be used safely on site. The measurement surface is V-shaped and stable even on pipes. (With magnet)Ulasan Produk
