Ultra-thin 1-pole flat relay with the world's lowest profile. The mounting area is reduced by 20% and the volume by approximately 64% (compared to OMRON's G5V-1), allowing for high-density mounting. Surface mount types are also available. Obtained UL/CSA standard in standard format. Completely abolished lead. RoHS compliant product.
Telephone-related equipment, communication equipment, measuring equipment, OA equipment, AV equipment, entertainment / amusement equipment, disaster prevention and crime prevention equipment, etc.
OMRON Surface mount relay G6L G6L-1P DC4.5 1pc
Rp63.900
Persediaan
Spesifikasi Produk
| Model Number | G6L-1P DC4.5 |
|---|---|
| Unit | 1pc |
| Shape | Plastic seal type |
| Coil Rated Voltage (V) | DC4.5 |
| Mass (g) | About 0.6 |
| Remark | Confirm delivery date each time |
| Type | Printed circuit board relays |
| Number of Poles | 1 |
| Rated Voltage (V) | DC4.5 |
| Contact Configuration | 1a |
| Terminal Shape | Printed circuit board terminal |
| Insulation Resistance (MΩ) | 1000 or more (at 500 VDC) |
| Terminal Structure | Printed circuit board terminal |
| Vibration Resistance (Destruction) | 10 to 55Hz 1.65mm single amplitude (3.3mm double amplitude) |
| Shock Resistance (Destruction) | 1000m/s<sup>2</sup> |
| Ambient Humidity to Use | 5~85%RH |
| Power Consumption (mW) | About 180 |
| Return Voltage | More than 10 |
| Operating Voltage | 75% or less |
| Vibration Resistance (Malfunction) | 10 to 55Hz 1.65mm single amplitude (3.3mm double amplitude) |
| Shock Resistance (Malfunction) | 100m/s<sup>2</sup> |
| Mechanical Durability | 5 million times or more (opening and closing frequency 36,000 times / h) |
| Electrical Durability | 100,000 times or more (rated load, switching frequency 1800 times / h) |
| Contact Material | Au alloy + Ag |
| Maximum Permissible Voltage (V) | 1.5 |
| M Code | 39069432 |
| Berat (Kg) | 0.1 |
| Tanggal Produk Terdaftar | 13 February 2026 |
| Terakhir Diperbaharui | 02 April 2026 |
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Feature
SpecificationSingle stable type
