Ultra-thin 1-pole flat relay with the world's lowest profile. The mounting area is reduced by 20% and the volume by approximately 64% (compared to OMRON's G5V-1), allowing for high-density mounting. Surface mount types are also available. Obtained UL/CSA standard in standard format. Completely abolished lead. RoHS compliant product.
Telephone-related equipment, communication equipment, measuring equipment, OA equipment, AV equipment, entertainment / amusement equipment, disaster prevention and crime prevention equipment, etc.
OMRON Surface mount relay G6L
#Grup produk P115126105
Spesifikasi
| Ambient Humidity to Use | 5~85%RH |
|---|---|
| Contact Configuration | 1a |
| Insulation Resistance (MΩ) | 1000 or more (at 500 VDC) |
| Mass (g) | About 0.6 |
| Number of Poles | 1 |
| Operating Voltage | 75% or less |
| Power Consumption (mW) | About 180 |
| Return Voltage | More than 10 |
| Shape | Plastic seal type |
| Shock Resistance (Destruction) | 1000m/s<sup>2</sup> |
| Type | Printed circuit board relays |
| Vibration Resistance (Destruction) | 10 to 55Hz 1.65mm single amplitude (3.3mm double amplitude) |
| Vibration Resistance (Malfunction) | 10 to 55Hz 1.65mm single amplitude (3.3mm double amplitude) |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Feature
SpecificationSingle stable type
