Mitsubishi Electric Inverter FR-A800 Series Standard Structure FR-A820-7.5K-E1 1pc

Name: Mitsubishi Electric Inverter FR-A800 Series Standard Structure FR-A820-7.5K-E1 1pc
Brand: Mitsubishi Electric
SKU: S049012224
Price: 34999900 IDR
Availability: InStock

#Nomor SKU S049012224

Wishlist

0 Ulasan

Spesifikasi Produk

Model Number	FR-A820-7.5K-E1
Unit	1pc
Spesifikasi	●Multiple speeds: 15 speeds●Abnormal output: 1c contact (AC230V0.3A, DC30V0.3A), open collector output, alarm code (4bit) output●Instantaneous power failure restart: Yes (frequency search method, reduced voltage method)
Dimensions (mm)	260Hx220Wx170L
Dimension H (mm)	260
Protection Class	Closed type (IP20)
Power Supply	(Rated input AC voltage / frequency) 3-phase 200-240 (50Hz / 60Hz)
Type of control	Soft-PWM control/High carrier frequency PWM control (select from V/F control, advanced magnetic flux vector control, and real sensorless vector control)/Optimal excitation control/Vector control/PM sensorless vector control
Approx. Mass (kg)	6.7
Dimension D (mm)	170
Output voltage (V)	3-phase 200-240
Dimension D1 (mm)	84
Dimension W (mm)	220
Power Supply Voltage (V)	(Rated input AC voltage / frequency) 3-phase 200-240 (50Hz / 60Hz)
Applicable Motor Capacity (kW)	7.5
Cooling Method	Forced air cooling
Dimension H1 (mm)	245
Frequency Range (Hz)	0.2 to 590 (The upper frequency limit is 400 for advanced magnetic flux vector control, real sensorless vector control, vector control, and PM sensorless vector control.)
Rated Input Current (A)	44.2 (standard load initial value)
Dimension H2 (mm)	1.5
Dimension W1 (mm)	195
Output Signal	Five types of open collector output and two types of contact output (1c contact) can be selected based on inverter operation, frequency arrival, frequency detection, operation preparation completion, overload warning, abnormal output, minor fault, etc.
Communication Function	Ethernet standard support, CC-Link, CC-Link IE Field Network, CC-Link IE, TSN, PROFIBUS-DP, DeviceNet(TM), SSCNETIII(/H), FL Remote option available
Regenerative braking torque	100%2%ED (maximum allowable utilization rate)
Starting Torque	SLD rating: 120% 0.3Hz, LD rating: 150% 0.3Hz, ND rating: 150% 0.3Hz, HD rating: 150% 0.3Hz (real sensorless vector control), SLD rating: 120% 0Hz, LD rating: 150% 0Hz, ND rating: 150% 0Hz, HD rating: 150% 0Hz (vector control)
Stall Prevention Operation Level	Stall prevention operation level operating range (SLD rating: 0 to 120%, LD rating: 0 to 150%, ND rating: 0 to 220%, HD rating: 0 to 280%), selectable (V/F control, advanced magnetic flux vector control)
M Code	39592684
Berat (Kg)	8.1
