Ball Vibrators K
Ball vibrators, simple and good. Wide range for many applications.
Properties
- Powerful
- Rated frequency 7’300 – 35’000 rpm
- Centrifugal force 130 – 4’050 N
- Continuously variable
- Applicable up to 100°C
- HT version up to 150°C on request
- Also available with ATEX certification
Field of application
- Emptying of bunkers
- Screen filters
- Vibrating tables
- Preventing adhesions in pipelines and silos
- Moving of bulk solids
Construction
- Vibration due to rotating ball running on hardened, ground steel guides.
- Nylon plates on both sides to support the ball and as pro tection against dust and water.
- Housing with 4 mounting bores.
Findeva Ball Vibrator K-25 1pc
Rp3.199.900
Persediaan
Spesifikasi Produk
| Model Number | K-25 |
|---|---|
| Unit | 1pc |
| Dimension A (mm) | 80 |
| Width (mm) | 38 |
| Dimension C (mm) | 128 |
| Dimensions d (mm) | 104 |
| Dimension E (mm) | 16 |
| Dimension F (mm) | 9 |
| Dimension G (mm) | 60 |
| Thread H (inch) | G 1/4 |
| Vibrations @2bar (x1000min-1) | 9.2 |
| Vibrations @4bar (x1000min-1) | 12.2 |
| Vibrations @6bar (x1000min-1) | 14.0 |
| Centrifugal Force @2bar (N) | 930 |
| Centrifugal Force @4bar (N) | 1570 |
| Centrifugal Force @6bar (N) | 2050 |
| Air Consumption at 2bar (L/minute) | 160 |
| Air Consumption at 4bar (L/minute) | 290 |
| Air Consumption at 6bar (L/minute) | 425 |
| Berat (Kg) | 0.6 |
| Tanggal Produk Terdaftar | 20 January 2023 |
| Terakhir Diperbaharui | 27 May 2025 |
