KHK Bronze Worm Wheel J Series BG1-30R1J8 1pc
Rp999.900
Persediaan
Spesifikasi Produk
| Model Number | BG1-30R1J8 |
|---|---|
| Unit | 1pc |
| Gear accuracy | KHK W 002 Grade 4 |
| Number of Teeth | 30 |
| Torsion Angle | 3°35' |
| Twist direction | R |
| Shape | H1T |
| Hole Diameter (mm) | 8 |
| Boss Diameter (mm) | 20 |
| Standard Circle Diameter (mm) | 30.07 |
| Tip Circle Diameter (mm) | 33 |
| Face Width (mm) | 10 |
| Boss Chief (mm) | 10 |
| Gear Reference Cross Section | Normal Angle |
| Tooth Finish | Cutting |
| Throat Diameter (mm) | 32 |
| Tooth Profile | Straight Teeth |
| Normal Module | 1 |
| Normal Pressure Angle | 20° |
| Material | CAC502 ; (PBC2) |
| Gear Reference Surface | Hole (H7) |
| Reduction Ratio | 30 |
| Accuracy class | KHK W 002 Grade 4 |
| Backlash (mm) | 0.06～0.24 |
| Dimensions a (mm) | 8 |
| Dimension Bs (mm) | 20 |
| Dimensions c (mm) | 30.07 |
| Dimensions ds (mm) | 32 |
| Dimensions d' (mm) | 33 |
| Dimensions j (mm) | 23 |
| Helix Angle | 3 ° 35 ′ (Torsion direction: R) |
| Hole Diameter | 8 |
| Modules | 1 |
| Number of Opponents | 1 |
| Shaft Hole Diameter (mm) | 8 |
| Spiral Angle | Right direction |
| Tooth Type | Normal teeth |
| Tooth Width (mm) | 10 |
| M Code | 17693077 |
| Berat (Kg) | 0.1 |
| Tanggal Produk Terdaftar | 07 October 2022 |
| Terakhir Diperbaharui | 21 November 2025 |
