Mitutoyo Analog Groove Micrometer Inch Non Rotating Spindle 146-231 0-1/0.0001inch 1pc
Rp5.599.900
Persediaan
Spesifikasi Produk
| Model Number | 146-231 |
|---|---|
| Unit | 1pc |
| Units | Inch |
| Spindle Type | Non-rotating |
| Range Inside (inch) | .055 - 1.05 |
| Range Outside (inch) | 0-1 |
| Flange Diameter (inch) | 0.25 |
| Accuracy (inch) | ±0.0004 |
| Graduation (inch) | 0.001 |
| Parallelism (inch) | 0.0004 or less |
| Technology | Mechanical |
| Measuring Force (N) | 0.7-1.2 |
| Ratchet/Thimble | Ratchet Stop |
| Berat (Kg) | 1.0 |
| Tanggal Produk Terdaftar | 13 December 2021 |
| Terakhir Diperbaharui | 15 August 2025 |
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
The Mitutoyo groove micrometer’s two-direction ratchet stop provides a constant measuring force on the spindle to ensure accurate, repeatable measurements of groove depths and widths. The sleeve and spindle contain measurements for both inside and outside diameters laser etched for precise, easy reading.
Feature
Available in Metric and Inch modelsGroove micrometer is available with a rotating and non-rotating spindle
Measuring discs are constructed precision ground hardened steel, precision in our Japanese factory
Ratchet mechanism provides an audible click to ensure measurement is performed with a constant force
Hardened measuring discs resist wear for better accuracy over time
Micrometer is precision balanced for easier handling and better readability
Satin chrome finish on the sleeve and laser etched measurements on sleeve and thimble for easier reading
Supplied in a plastic, fitted case
