Mitutoyo Dial Caliper Gage 209-404 20/.01mm 1pc
Rp10.999.900
Persediaan
Spesifikasi Produk
| Model Number | 209-404 |
|---|---|
| Unit | 1pc |
| Units | Metric |
| Max Range (mm) | 20 |
| Graduation (mm) | 0.01 |
| Accuracy (mm) | ±0.03 |
| Maximum Measuring Depth (mm) | 85 |
| Upper Meas Cont lgth (mm) | 7 |
| Lower Meas Cont Lgth (mm) | 24.6 |
| Upper Meas Cont Type | Ball |
| Lower Meas Cont Type | Ball |
| Upper Measuring Diameter (mm) | 1.5 |
| Lower Measuring Diameter (mm) | 1.5 |
| Berat (Kg) | 1.0 |
| Tanggal Produk Terdaftar | 13 December 2021 |
| Terakhir Diperbaharui | 15 August 2025 |
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
The Mitutoyo external dial caliper gage utilizes spring-loaded jaws to provide constant point contact pressure to take highly accurate comparison measurements of hole diameters and groove and tube thicknesses. The dial display provides precise, readable measurements in metric or inches.
Feature
Available in Metric and Inch modelsAvailable in ranges up to 50mm/2”
Available with different types of jaws for various application needs
Indicator should be used in conjunction with a setting ring or micrometer
White dial face for easier, precise measurement readings
Crystal is glare-free with a scratch-resistant coating
IP65 Rating resists dusts and liquid penetration up to the force of a low-pressure water jet
Supplied in a fitted plastic case
