OMRON Safety Relay G7SA G7SA-3A3BDC110 1pc

Name: OMRON Safety Relay G7SA G7SA-3A3BDC110 1pc
Brand: OMRON
SKU: S029714568
Price: 359900 IDR
Availability: InStock

#Nomor SKU S029714568

Wishlist

0 Ulasan

Spesifikasi Produk

Model Number	G7SA-3A3BDC110
Unit	1pc
Contact Configuration	3a3b
Number of Poles	6
Outer Dimensions (mm)	50 or less x 13 or less x 24 or less
Protection Class	Flux resistant type
Rated Voltage (V)	DC110
Response Time	10 ms or less
Insulation Resistance (MΩ)	1000 or more (DC500V insulation resistance meter)
Operating Ambient Temperature (°C)	-40 to +60 (however, no freezing or condensation)
Contact Resistance (miliΩ)	100 or less (DC5V 1A voltage drop method)
Ambient Relative Humidity (RH)	5 to 85
Mechanical Durability (times)	10 million (opening and closing frequency 36,000 / h)
Electrical Durability (times)	100,000 or more (rated load, switching frequency 1800 / h)
Coil Resistance (ohm)	20862
Maximum Switching Frequency (times/hour)	36000
Failure Rate P Level (V-mA)	(Reference Value: at Switching Frequency 120 times/min) DC5-1 (opening and closing frequency 300 times/min)
Operating Time (ms)	20 or less (ambient temperature 23 ° C)
Vibration Resistance	10~55~10 Hz, single amplitude 0.75 mm (double amplitude 1.5 mm)
M Code	66490768
Berat (Kg)	0.5
Tanggal Produk Terdaftar	23 November 2021
Terakhir Diperbaharui	01 April 2026

Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini

Informasi Produk

Deskripsi

ada

Description

EN slim standard safety relay with a forced guide contact (EN50205/Class A VDE certified) .
Backs up the CE marking (machine directive) of the machine.
By adopting an interlock circuit configuration, the dangerous state of the machine is avoided.
Available in 4 and 6 positions.
Terminal arrangement for easy PWB pattern drawing.
Reinforced insulation between input and output. Reinforced insulation is also provided between parts of different poles.
* The response time is the time from when the coil voltage is turned off until contact a turns off, including the bounce time.
The rated current and coil resistance are measured at a coil temperature of 23°C, with a tolerance of ± 15%.
* Operating characteristics are measured at a coil temperature of 23°C.
* When used with a socket (P7SA) , the Withstand voltage between coil contacts/different poles is 2500 VAC 50/60 Hz for 1 min.

Warning

The response time includes the bounce time until the A contact is turned off after the coil voltage is turned off.
Rated current, coil resistor is a value at 23°C, the tolerance is ± 15%.
Operating characteristics are values at 23°C coil temperature.
When used in socket (type P7SA) , the Withstand voltage between the coil contacts/ectodoids is AC2500V 50/60 Hz 1 min.

Feature

Small slim safety relay that has acquired EN standard
Relay with forced guide contact (EN50205/Class A VDE certification) .
Back up the CE marking (machine directive) of the machine.
By adopting an interlock circuit configuration, the dangerous state of the machine is avoided.
Assortment of 4 poles and 6 poles.
Terminal arrangement that makes it easy to route the PWB pattern.
Reinforced insulation between input and output. Reinforced insulation for a part between different poles.

Withstand Voltage
Between coil contacts, between different poles (6 poles: 3-5 poles, 4-6 poles, 5-6 poles excluded): AC4000V 50 / 60Hz 1min Different poles (3-5 poles, 4-6) Between poles, between 5-6 poles): AC2500V 50 / 60Hz 1min Between contacts of the same pole: AC1500V 50 / 60Hz 1min
