Waterproof connector for FA pursuing reduced man-hours, maintenance and environmental resistance.
Compliant with IP67. Compact connector for FA that achieves 94V-0 flame resistance.
Wiring system connector makes facility maintenance easier and reduces facility downtime.
* Crimp type socket contacts are sold separately.
OMRON Round Waterproof Connector (M12) with Cable Socket One Side Connector XS2 L Type XS2F-D422-H80-F 1pc
Rp569.900
Persediaan
Spesifikasi Produk
| Model Number | XS2F-D422-H80-F |
|---|---|
| Unit | 1pc |
| Cable | Flame-retardant, bending-resistant cable |
| Color | Contact block: light gray |
| Insulation Resistance (MΩ) | 103 or more (at 500 VDC) |
| Cover Material | Soft PBT (UL94V-0) |
| Cable Length (m) | 7 |
| Material (O-ring) | Rubber |
| Rated Voltage (V) | DC250 |
| Operating Humidity Range | 20 to 85%RH |
| Tensile Strength (N/s) | Assembly part fixed: 98/15 |
| Rated Current (A) | 1.5 |
| Protection Class | IP67(IEC529) |
| Operating Temperature Range (°C) | -25 to +70 |
| Number of Poles | 4 |
| Type | Connector socket with cable One side connector |
| Contact Resistance (miliΩ) | Connector: 40 or less (20mV or less, 100mA or less) |
| Connector | One side connector |
| Core x Size (mm²) | 4x0.5 |
| Contact Material | Phosphor bronze |
| Cable Holding Strength (N/15s) | Outer diameter Φ6: 98, Outer diameter Φ4~Φ5: 49, Outer diameter: Φ3: 29 |
| M Code | 46682291 |
| Berat (Kg) | 0.2 |
| Tanggal Produk Terdaftar | 23 November 2021 |
| Terakhir Diperbaharui | 01 April 2026 |
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Warning
Crimp type socket contact is sold separately.Feature
Waterproof connector for FA that pursues departure and saving maintenance and environmental resistance.Meet IP67. FA-only compact connector that achieves flame retardancy of 94V-0.
Connectorization of wiring systems facilitates equipment maintenance and shortened equipment downtime.
