SKF Single Row Deep Groove Ball Bearing dengan Segel Tipe 2Z/C3 (Laher) 6005-2Z/C3 1pc

#Nomor SKU S017158527
Wishlist
Rating:
100% of 100
(1)
Rp49.000
Persediaan

Spesifikasi Produk

Model Number 6005-2Z/C3
Unit 1pc
Bore Diameter d (mm) 25
Outside Diameter D (mm) 47
Width B (mm) 12
Dimension D1 (mm) 32
Dimension D2 (mm) 42.2
Dimensions r1,2 (mm) min. 0.6
Diameter of Shaft Abutment da (mm) min. 28.2; max. 31.9
Diameter of Housing Abutment Da (mm) max. 43.8
Dimensions ra (mm) max. 0.6
Basic Dynamic Load Rating (kN) 11.9
Basic Static Load Rating (kN) 6.55
Fatigue Load Limit (kN) 0.275
Reference Speed (rpm) 32000
Limiting Speed (rpm) 16000
Number of Rows Single Row
Bore Type Cylindrical
Cage Sheet Metal
Radial Internal Clearance C3
Bearing Material Bearing Steel
Coating Without
Sealing Shield on Both Sides
Sealing Type Non-Contact
Lubricant Grease
Berat (Kg) 0.1
Tanggal Produk Terdaftar 26 August 2020
Terakhir Diperbaharui 21 July 2025
ask-button

Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini

Informasi Produk

Description
Single row deep groove ball bearings with seals or shields are particularly versatile, have low friction and are optimized for low noise and low vibration, which enables high rotational speeds. They accommodate radial and axial loads in both directions, are easy to mount, and require less maintenance than many other bearing types. The integral sealing can significantly prolong bearing service life because it keeps lubricant in the bearings and contaminants out.
Warning
Image may differ from product. See the technical specification for details.
Feature
- Integral sealing prolongs bearing service life
- Simple, versatile and robust design
- Low friction and high-speed capability
- Accommodate radial and axial loads in both directions
- Require little maintenance
