Kitz T Ball Valve TKT (ROHS Compliant) TKT (GS 101) 8A 1pc
Rp559.900
Persediaan
Spesifikasi Produk
| Model Number | TKT (GS 101) |
|---|---|
| Unit | 1pc |
| Material (Handle) | ZDC2 |
| Body Material | C3771BE |
| Material (bonnet) | C3604BD:1/8B |
| Cap Material | C3604BD:1/8B |
| Material (stem) | C3531 |
| Nominal Diameter | 8A |
| Dimension L (mm) | 39 |
| Dimensions d (mm) | 35 |
| Dimension H (mm) | 23 |
| Ball Material | C3771BE+Ni-Cr-plated |
| Material (disk) | C3771BE+Ni-Cr-plated |
| Connection Shape | Screw: JIS B0203 |
| Vapor Pressure (MPa) | 0.98 (saturated vapor) |
| Operation | T-shaped handle |
| Bore Diameter | Redeyusutoboa |
| Material (ball seat) | Fiberglass entry PTFE |
| Material (Packing) | Fiberglass entry PTFE |
| Compliance standard | Nissui Association Certificate No.: E-2 custom (3/8B-1 1/2B), RoHS Directive equivalent: Custom (1/8B-1B) |
| Maximum Permissible Pressure (MPa) | 4.12 (ordinary temperature of water, oil, combustible, gases other than toxic gas) |
| M Code | 66086703 |
| Berat (Kg) | 6.5 |
| Tanggal Produk Terdaftar | 18 January 2019 |
| Terakhir Diperbaharui | 09 January 2026 |
