PISCO Rotary Actuator Turntable Type HR400-90DA 1pc

#Nomor SKU S006972073

Spesifikasi Produk

Model Number	HR400-90DA
Unit	1pc
Option	Magnetic sensor
Stroke	2.2cm
Operating Temperature Range	5 to 60°C
Cushion	Air cushion system
Operating Pressure Range	0.3 to 0.8MPa
Actuation	Double acting type (rack and pinion type)
Swing Angle	90 degree
Fluid	Compressed air (no lubrication)
Angle Adjustment Range	0 to + 5°
Torque	6N/m
Cross-sectional Area	Cylinder/12.9mm²
Port Size	M5x0.8 mm
Rotation Angle	90°
Tolerable Thrust Load	26.46N
Allowable Kinetic Energy	0.015N/m
Allowable Radial Load	Shaft/45.08N
M Code	87967643
Berat (Kg)	0.6
Tanggal Produk Terdaftar	03 October 2018
Terakhir Diperbaharui	02 April 2026
