The construction of this ball bearing is similar to mounting two single row angular ball bearings back to back(DB).
Capacities of double row ball bearing is less than single row since few balls can be inserted per row.
This bearing type can sustain radial, moment and bi-directional axial loads.
NACHI Double Row Angular Contact Ball Bearing 5312 1pc
Rp859.900
Persediaan
Spesifikasi Produk
| Model Number | 5312 |
|---|---|
| Unit | 1pc |
| Shield Form | Open form |
| Outside Diameter D | 130Φmm |
| Standard Dynamic Load Rating Cr | 128000N |
| Outer Ring Type | flat |
| Load Direction | radial |
| Allowable Rotational Speed Oil Lubrication | 5000min-1(r.p.m( Oil Lubrication |
| Inside Diameter d | 60Φmm |
| JIS Grade | - |
| Chamfer Dimensions r | 2.1 minimum |
| Mounting Dimensions | 72Minimum damm |
| Width B | 54mm |
| Standard Static Rating Load Cor | 101000N |
| Allowable Rotational Speed Grease Lubrication | 3800min-1(r.p.m( Grease Lubrication |
| Rolling Element Material | High carbon chromium bearing steel |
| Track Ring Form | Angular contact ball bearing |
| Material | 2 |
| Track Ring Line Number | 30 degree |
| M Code | 7029041 |
| Berat (Kg) | 0.2 |
| Tanggal Produk Terdaftar | 17 September 2018 |
| Terakhir Diperbaharui | 27 May 2025 |
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Use
Application:Blower
High speed vacuum pump
Super charger
Motor cycle transmission
