Proto-Rios Body dimension drawing plus 2022 edition

The measurement reference position and dimensions, which are indispensable for body repair work, are obvious at a glance! The body measurement chart collection, which has been used regularly since its publication in 1983, has been published in the body shop report with increased content and data since 2018. The data of "structural research by vehicle type" has been compiled into one volume. Abundant recorded data! In addition to dimensional data, wheel alignment values, undercoat application positions, etc. are introduced in an easy-to-understand manner. All colors! It's even clearer and easier to see. The format has also changed from horizontal to vertical. The content of the publication is the same as the "structure research by car model" published in the body shop report. Corrections to dimensions and additions to grades have been recorded since the body shop report was published.
*[Important Notice] Regarding the posting of Toyota vehicles (*After 2021) Due to the revision of the rules for reprinting illustrations, they will not be posted. Also, for the same reason, there is no information in the corrected information of the model posted in the past and in the article "Structural Research by Model" in the monthly body shop report. *Please note that we do not allow the distribution of dimension drawings by fax or other means due to copyright issues.
