SIGMAKOKI Plate thin beam splitter MPSMH-30C0 series

Sebelum PPN:
Rp15.999.900

Pilih jenis produk yang diinginkan

Nomor SKU Model Number Masa Persiapan Barang Harga Jumlah
Loading...
ask-button

Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini

Informasi Produk

Description
This is a beam splitter with a substrate that is as thin as possible. Even when inserted into the optical path, it can extract reflected light without affecting the beam shift or wavelength dispersion of the transmitted light.
Feature
Specification
( Common Specifications)Material: Synthetic quartz, Coating: Surface dielectric multilayer film, Back side (45° tapered hole side) anti-reflective film, Incident angle: 45°, Transmittance: Average 50±5% (average value of P-polarized and S-polarized light), Splitting ratio (reflection:transmission): 1:1, Scratch-dig: 40-20, Effective diameter: DIA10mm, Frame material: Holding glass synthetic quartz, Outer frame aluminum, Surface treatment: Matte black anodized, (Individual Specifications)Applicable wavelength: 400-700nm, Element thickness: 0.09±0.01mm, Coating back surface precision: Reflection: Optical polishing, Transmission: Optical polishing

Ulasan Produk

Tidak ada ulasan
