SIGMAKOKI Joystick Terminal

Specification
(<2-axis stage controller> Common Specifications) Main Functions: Controller function: ○, Number of control axes: 2 axes, Built-in program control: △, Feedback control: -, Circular interpolation control: -, Linear interpolation control: -, Driver function: Standard, Microstep (maximum divisions): 2 divisions (half step only), Drive current: 0.3-0.8A/phase, General specifications: Power supply voltage: DC24V 2A, General specifications: Power consumption: 48VA, General specifications: Operating temperature: 5-40°C, General specifications: Storage temperature: -20-60°C, General specifications: Ambient humidity: 20-80%RH, General specifications: External dimensions (WxHxD): 180x40x125mm, General specifications: Weight: 0.7kg, Interface GP-IB: -, Interface RS232C: ○, Interface USB: - Interface Ethernet: -, Option CJ-200A: -, Option JS-300: -, Option JB-400: -, Option SJT-02: ○, Performance Specifications Coordinate Display Range: -, Performance Specifications Maximum Set Movement Amount: 16777214, Performance Specifications Maximum Drive Speed: 20,000 pps, Performance Specifications Minimum Drive Speed: 1 pps, Performance Specifications Acceleration/Deceleration Time: 0-1,000 ms, I/O Specifications Origin Sensor: ○, I/O Specifications Proximity Sensor: ○, I/O Specifications CW(+) Limit: ○, I/O Specifications CCW(-) Limit: ○, I/O Specifications General Purpose Input: -, I/O Specifications General Purpose Output: -, I/O Specifications Control Input: -, I/O Specifications Control Output: -, I/O Specifications Trigger Output: -, Control Command Machine Home Position Return: ○ Control command Logical origin setting: ○, Control command Relative position drive: ○, Control command Absolute position drive: -, Control command Jog operation: ○, Control command Position specification: -, Control command Arc interpolation control: -, Control command Linear interpolation control: -, Control command Drive: ○, Control command Deceleration stop: ○, Control command Emergency stop: ○, Control command Speed ​​setting: ○, Control command Motor free/hold: ○, Control command Port input: -, Control command Port output: -, [Individual specifications] Product name: Joystick terminal, Type: Joystick, Power supply: Supplied from controller, Display: LCD (16 digits x 2 lines), External dimensions: W94 x H30 x D140 mm, Weight: 0.45 kg
