SIGMAKOKI Chrome cube half mirror CSCH series

Sebelum PPN:
Rp3.099.900 - Rp18.999.900

Pilih jenis produk yang diinginkan

Nomor SKU Model Number Masa Persiapan Barang Harga Jumlah
Loading...
ask-button

Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini

Informasi Produk

Description
This cube-type half mirror can be used in a wide wavelength range from visible to infrared. It can be used for simple experiments and spectroscopic measurements.
Feature
Specification
( Common Specifications)Material: BK7, Substrate Surface Accuracy: λ/4, Transmitted Beam Deflection: <5′, Coating: Chrome film on beveled surfaces, Anti-reflective coating on all four sides, Incident Angle: 0°, Transmittance: Average 28±5% (average value of P-polarized and S-polarized light), Branching Ratio (Reflection:Transmission): 1:1, Laser Power: 0.3J/cm2 (Pulse width 10ns, Repetition frequency 20Hz), Scratch-Dig: 40-20, Effective Range: Circle inscribed in a square with 85% of the outer dimensions, (Individual Specifications)Applicable Wavelength: 400-700nm, A=B=C: 50mm
