ASA ELECTRONICS INDUSTRY Ball Coupling Mini Ball Coupling (Single) MBS

• Universal joint with added allowable end play function. • Simple structure with three elements: outer hub, inner hub (stainless steel), and ball. • Small and powerful, ideal for miniaturizing mechanisms. • Uses high-viscosity special grease. • MBS15-32 sizes allow for left and right different diameter combinations. • Ball couplings are rotational transmission elements that combine the functions of universal joints and splines. • The ball coupling, consisting of three elements: inner hub, outer hub, and ball, has a patented functional structure. • No size limitations, expanding possibilities from micro-sized to large couplings. • High transmission capacity relative to external size, especially high breakage torque, enables miniaturization of equipment. • No basic restrictions on hub and ball material, allowing for use in water, oil, high temperature, and low temperature vacuum. • Couplings with angle and eccentricity (spline) amounts can be designed to suit the required usage in actual applications. • Future applications are expected, from micro-robots to automated machines, packaging machines, and large industrial machinery. • High-speed, high-rigidity servo compatibility can also be considered.
