This is an expansion board for the "SPRESENSE Main Board," a board computer for IoT that is low power consumption yet equipped with GPS reception and a high-resolution audio codec.
The device is equipped with the CXD5610GF GNSS receiver LSI manufactured by Sony Semiconductor Solutions, which achieves dual-band positioning using the L1 and L5 bands. This enables highly accurate and stable positioning even in harsh environments with reflections from the ground and nearby buildings.
Positioning satellite system: GPS (L1C/A, L5), GLONASS (L1OF), BeiDou (B1I, B1C, B2a), Galileo (E1 CBOC, E5a), QZSS (L1C/A, L1S, L5), SBAS (L1), NavIC (L5))
*This product does not include a GNSS antenna. A separate external antenna is required.
*The connection terminal is U.FL standard, so if you use a GNSS antenna with an SMA connection, you will need to prepare a separate U.FL (male) to SMA (female) conversion cable.
*This product does not have an LNA, so only active antennas can be used; passive antennas cannot be used.
SONY SPRESENSE GNSS Add-on Board
#Grup produk P116539999
Spesifikasi
| Antenna | External antenna |
|---|---|
| Dimensions (mm) | 33.0 x 20.6 |
| Frequency | L1/L5 |
| Interface | [Control] 2C: 2pin, Interrupt: 1pin |
| ROHS Directive (Corresponding to 10 Substances) | Correspondence |
| Voltage (V) | IO:DC 1.8 |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Feature
SpecificationGNSS reception sensitivity: Cold start: -149 dBm
Hot start: -165 dBm
Tracking: -167 dBm; NSS Receiver LSI: CXD5610GF; Antenna Connector: U.FL; Initial Position Calculation Time: Cold Start: Approx. 24 seconds; Hot Start: Approx. 1 second
