Lascar Lascar Digital Panel Meter TFT PanelPilot Series

Specification
*Characteristics Measurement: Voltage*Display Type: TFT*Height: 54.5mm*Width: 87mm*Depth: 17.8mm*Operating Temperature Min: 0°C*Operating Temperature Max: +40°C*Measurement Range: 0 to 40V dc*Series: PanelPilot*Lascar Smart GraphicsLascar PanelPilot series 2.8 inch smart graphic displays feature a 320 x 240 pixel (QVGA) color display and a USB programming interface. Using the PanelPilot software (available for Windows 7, 8.1, and 10), users can customize the type of voltmeter to suit their needs. Users can customize colors, text labels, splash screens, and input voltage scaling using the software and upload it to the meter using the USB connection. Once programming is complete, all selections can be saved to the meter and computer, unplugged, and mounted on a panel like a standard display. Features and Benefits Voltage measurement range: 0 -> 40 V dc Multiple voltmeter configurations included free of charge Pixel-resolution TFT display with touch screen technology Programmable via USB interface Accuracy: 0.05% Simple panel mounting solution with screw terminal connections Wide operating voltage range: 4 -> 30 V dc Digital hold 54.5mm height, 87mm width and 17.8mm depth cut out Operating temperature range: 0 -> 40°C Certified ANSI/ESD S20.20:2014 BS EN61340-5-1:2007
