HARWIN HARWIN Connector Housing 12 poles Pitch: 1.25mm 2 rows G125-2041296L0

Specification
*Number of poles: 12*Number of rows: 2*Pitch: 1.25mm*Male/female: Female*Mounting type: Cable mount*Series: Gecko*Compatible with: Crimp contact G125-0010005, Crimp contact G125-0020005*Connection direction: Straight*Length: 10.05mm*Width: 4.9mm*Housing material: Polyamide*Harwin 1.25 mm Gecko series crimp socket housing. This Gecko series 1.25 mm pitch wire-to-board crimp socket housing features high density 1.25 mm pin spacing and a low profile miniature design to provide high performance and reliability while saving board space. This Gecko crimp socket housing features enhanced strain relief with a rear potting wall and can withstand harsh temperatures from -65 -> +150°C. The three-point polarity of the crimp housing prevents mis-mating. The contact position for number 1 is also marked on the housing. Contacts for this Gecko crimp housing are sold separately (see typical part number: 909-4240 909-4240).
