onsemi onsemi Rectifier Diode, 1A, 400V Surface Mount, 2-Pin DO-214AA (SMB) AEC-Q101 1.05V

Mounting Type = Surface Mount Package Type = DO-214AA (SMB)
Maximum continuous forward current = 1A
Peak reverse repetitive voltage = 400V
Diode Configuration = Single Rectifier Type = Switching Diode Type = Rectifier Pin Count = 2
Maximum forward drop voltage = 1.05V
Number of elements per chip = 1
Peak reverse recovery time = 75ns
Peak non-repetitive forward surge current = 35A
Ultrafast rectifiers are ideal for high voltage, high frequency rectification or freewheeling/protection diodes in surface mount applications where compact size and weight are critical to the system. Small compact surface mountable package with J-leads Prismatic package for automated handling Heat resistant glass passivated junctions Low forward voltage drop (0.71 → 1.05V max @ 1.0A, TJ = 150°C) Mechanical Properties: Case: Epoxy, Molded Weight: Approx. 95 mg Finish: Corrosion resistant on all external surfaces; Terminal Leads are easily solderable Soldering lead and mounting surface temperature: Max. 260°C for 10 seconds Polarity: Polarity band indicates cathode lead Lead-free package
