Lovato Monitoring relay Lovato SPDT 24 → 240V ac / dc 64.9mm

Specification
Monitoring application: Current * Power supply voltage: 24 -> 240 V ac / dc * Contact configuration: SPDT * Electrical phase: 1 * Current sensitivity: Overcurrent * Minimum detection current: 0.25A * Maximum detection current value: 16A * Delay time: 0.1 -> 30 seconds * Dimensions: 35.8 x 64.9 x 104.7 mm * EAC, US and Canada UL compliant as auxiliary device (cULus file E93601) Compliant standard: IES / EN60255-5 IEC / EN61000-6-2 IEC / EN61000-6-3 UL508 CSA C22.2 n ° 14. Current monitoring relay AC / DC single phase. Lovato's current monitoring relay supports AC / DC min / max current control of AC / DC multi-voltage auxiliary power supplies for single phase systems. .. The current monitoring relay can be used with a direct connection of up to 16 A or via a rectifier. It has excellent trip accuracy and can support TRMS current measurement. With one or two relay outputs and one switching contact SPDT, all types have an automatic / manual reset function. Modular DIN43880 housing Excellent trip accuracy IEC protection: IP40 (front) IP40 only when placed in enclosure or control board IP20 (terminal) Single-phase system AC / DC max / min current control Delayed trip auxiliary AC / DC power supply TRMS current measurement Automatic or manual reset of the reset and input suppression. Single-phase current monitoring relay
